Factory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with Encoder

Product Description

MEMA23 closed loop Stepper Motor 2phase hybrid Servo stepper motor with Driver
General Specification:
ItemSpecifications
Step Angle1.8°
Temperature Rise80ºCmax
Ambient Temperature-20ºC~+50ºC
Insulation Resistance100 MΩ Min. ,500VDC
Dielectric Strength500VAC for 1minute
Shaft Radial Play0.02Max. (450g-load)
Shaft Axial Play0.08Max. (450g-load)
Max. radial force75N (20mm from the flange)
Max. axial force15N
Electrical Specification:

Model No.

Step Angle

Motor Length

Current
/Phase

Resistance
/Phase

Inductance
/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass
 ( °)(L)mmAΩmHN.mNo.g.cmg.cmKg
JK57HS41-4204BFED-0.35M1.8414.20.30.70.5542501500.65
JK57HS56-4204BFED-0.35M1.8564.20.41.21.143502800.98
JK57HS76-4204BFED-0.35M1.8764.20.61.81.846004401.1
JK57HS82-4204BFED-0.35M1.8824.20.72.52.2410006001.2
JK57HS112-4204BFED-0.35M1.81124.20.93.83.1412008001.4

Products of special request can be made according to the customer request !

Factory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with EncoderFactory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with EncoderFactory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with EncoderFactory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with Encoder


company information:
Factory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with Encoder
our certification:
Factory Price NEMA23 Closed Loop Stepper Motor 2phase Hybrid Servo Stepper Motor with Encoder

Our Company offers three major series of products:Hybrid Stepper Motors, Brushless Dc Motor and Dc Brush Motor.
We are always continues develop new type models.If you need other kinds of parts, please don't hesitate to contact us.
