Automatic Screw Locking Machine With Screw Feeder driver

  • Automatic Screw Locking Machine With Screw Feeder driver
  • Automatic Screw Locking Machine With Screw Feeder driver
  • Automatic Screw Locking Machine With Screw Feeder driver
  • Automatic Screw Locking Machine With Screw Feeder driver

Automatic Screw Locking Machine With Screw Feeder driver

    Packaging: Thickened corrugated cardboard
    Productivity: 20000sets/Year
    Brand: NBU
    Transportation: Ocean,Air,Express
    Place of Origin: China
    Supply Ability: 2000sets/month
    Port: NINGBO,SHENZHEN,GUANGZHOU

Basic Info

Model No.: MDE-1050

Product Description

High Efficiency Pneumatic Hand-held Type Automatic Screw Locking Machine With Screw Feeder Driver

1. Wide range of applicable screws
Widely used in M1.0-M5.0 various types and length screws, such as standard screws, 1:1 short screws, self-tapping screws, with gasket screws, rivets, sheets and small nuts.
2. Resistance to strong light interference
The screw induction is not disturbed by strong light, and it can still work normally under strong light, and the adaptation environment is wider.
3. Smooth operation
The screw runs in the drum. Any screw that does not enter the track in the normal direction will fall into the drum and enter the next cycle, without jamming.
4. Display counting function
Accurate counting, cycling, with LCD panel.
5. Feeding efficiency can be adjusted
The feeding and vibration are independently controlled, and the ideal feeding speed and vibration size can be set freely. The four-division disc pauses independently and can be set according to different screws and user requirements, which is suitable for various operations.
6. Fault alarm function
When an abnormal situation occurs, such as a shortage of material, the screw machine automatically activates the alarm function.
7. Low noise and small size
Small size, no space, convenient and practical.
8. Overload protection
Fully upgrade the control board, for the feeding motor and the indexing Stepper Motor, when the card is in stock, the system automatically controls the motor to reverse for a certain period of time to avoid overloading the motor or circuit board.
9. Anti-leak reminder
The number of screws that can be locked by the product can be better controlled to prevent the phenomenon of screw leakage and the feeding is more accurate.


3132333435Mde 1050
