NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor

Product Description

1.8° 86mm Hybrid Stepper Motor-NEMA34
Genaral Specification:
Step Angle ------------------- 1.8° ± 5%
Temperature Rise ------------- 80° Max
Ambient Temperature -------- -20° ~+50°
Insulation Resistance--------- 100 MΩ Min., 500VDC
Dielectric Strength: ------------ 1800VAC for 1S 5mA
Shaft Radial Play --------------- 0.02Max. (450g-load)
Shaft Axial Play ----------------- 0.08Max. (450g-load)
Max. Radial force----------------- 220N (20mm from the flange)
Max. Axial force------------------- 60N
Model No.  Step AngleMotor LengthCurrent
/Phase
Resistance
/Phase
Inductance
/Phase
Holding Torque  # of Leads  Detent TorqueRotor Inertia  Mass
( ° )(L)mmAΩmHN. mNo.Kg. cmg. cmKg
JK86H66-59041.8665.90.281.73.440.810001.7
JK86H66-28081.8662.81.43.93.480.810001.7
JK86H78-55041.8785.50.4644.641.214002.3
JK86H78-42081.8784.240.753.44.681.214002.3
JK86H97-40081.89740.984.16.881.619003
JK86H97-50081.89750.652.46.881.619003
JK86H97-27081.8972.71.98.66.881.619003
JK86H115-60041.811560.66.58.742.427003.8
JK86H115-42081.81154.20.968.782.427003.8
JK86H126-40081.812641.35.89.383.032004.5
JK86H126-50081.812650.853.49.383.032004.5
JK86H126-27081.81262.72.512.59.383.032004.5
JK86H153-62041.81536.20.7591243.640005.4
JK86H153-42081.81534.21.2581283.640005.4


NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor
NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor
NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor
NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor
NEMA 34 High Torque 12.2n. M 2 Phase 1.8 Degree 86mm Stepper Motor






Contact us if you need more details on Stepper Motors. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Stepping Motor、Step Motor. If these products fail to match your need, please contact us and we would like to provide relevant information.
