Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine

Product Description


Descriptions:

ItemValue
Warranty1 Year
Place of OriginChina
Brand NameJkongmtor
Model No.JK86HS78-5504
Phase2
TypeHybrid
Current/Phase5.5A
CertificationCE, Rohs
Holding Torque4N.m-4.6N.m,
Motor Length78MM
Diameter of Axle67-155MM
Number of Leads4 leads or 8 leads
Resistance0.46Ω
Inductance4mH -8mH
Shaft TypeD-Cut Shaft or Round Shaft
TypeNema34 Stepper Motor

Product Paramenters:
Step angle:1.8° Temperature rise:below 80 ºC
Ambient temperature:-20 ºC ~ + 50 ºC
Insulation resistance:minimum 100MΩ, 500VDC
Dielectric strength:820VAC for 1 minute
Shaft radial clearance 0.02 max (450 g load)
Shaft axial clearance:0.08Max. (450 g load)
Maximum radial force:220N (20mm from flange)
Maximum axial force:60N

Model Name: JK86HS78-5504
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:5.5A
Resistance:0.46Ω
Inductance:4mH
Holding Torque:4.5N.m
Motor length:78mm
Number of leads: 4leads
Shaft Dia: 12mm or 12.7mm
Shaft Type: Round Shaft or D-cut Shaft

Model Name: JK86HS115-6004
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:0.6Ω
Inductance:6.5mH
Holding Torque:8.5N.m
Motor length:115mm
Number of leads: 4leads

Model Name: JK86HS155-6004
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:1Ω
Inductance:0.68mH
Holding Torque:12.5N.m
Motor length:155mm
Number of leads: 4leads


Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC MachineHot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC MachineHot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine
Detailed Image:
Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine


Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine
Company File:
Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine

Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine
Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine
Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine
Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC MachineHot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine

   Hot Sale 1.8 Degree 4n. M Holding Torque NEMA34 Step Motor for CNC Machine

WHY YOU CHOOSE US:

We are a professional manufacturer for Stepper motor , Stepper Driver, BLDC motor and DC motor. we can supply OEM service.
Our products all with CE and ROHS.
Welcome you visit our company Changzhou Jingkong Motor&Electric Appliance Co.,Ltd

Depending on advanced technology and knight service, we establish a good and diligent team and keep nice business relationship with a large amount of worthy clients in global market. We are prepared to provide the best products to clients at competitive price.


High quality
Competitive price
Good Packing
Fast Delivery
Knight service
Advanced technology

Believe that we will do our best!

Model No.Step AngleMotor LengthCurrent
/Phase
Resistance
/Phase
Inductance
/Phase
Holding Torque# of LeadsDetent TorqueRotor InertiaMass
( °)(L)mmAΩmHN.mNo.kg.cmg.cm2Kg
JK86HS68-59041.8675.90.281.73.440.810001.7
JK86HS68-28081.8672.81.43.93.480.810001.7
JK86HS78-55041.8785.50.464.04.641.214002.3
JK86HS78-42081.8784.20.753.44.681.214002.3
JK86HS97-45041.8974.50.663.05.841.721003.0
JK86HS97-40081.8974.00.984.14.781.721003.0
JK86HS100-60041.81006.00.362.87.041.922003.1
JK86HS115-60041.81156.00.66.58.742.427003.8
JK86HS115-42081.81154.20.96.08.782.427003.8
JK86HS126-60041.81266.00.586.56.342.932004.5
JK86HS155-60041.81556.00.689.013.043.640005.4
JK86HS155-42081.81554.21.258.012.283.640005.4
