CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS

Product Description




               60mm 2phase Hybrid Stepper Motor for cnc machine



General Specification:

Step Angle  Accuracy: ±5%
Resistance Accuracy: ±10%
Inductance Accuracy: ±20%
Temperature Rise: 80°C Max
Ambient Temperature: -20°C~+50°C
Insulation Resistance: 100MΩ Min., 500VDC
Dielectric Strength:  500VAC for one minute
Shaft Radial Play:  0.02Max (450g-load)
Shaft Axial Play: 0.08Max (450g-load)
CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS
Specification
Model No.
Motor Length

Current
/Phase

Resistance
/Phase

Inductance
/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass
 (L)mmAΩmHN.mNo.g.cmg.cmKg
JK60HS56-2008unipolar5621.83.1.1787003000.77
parallel2.80.93.61.65
Series1.43.614.41.65
JK60HS67-2008unipolar6722.44.61.589005701.2
parallel2.81.24.62.1
Series1.44.818.42.1
JK60HS88-2008unipolar88236.82.2810008401.4
parallel2.81.56.83.1
Series1.4627.23.1
JK60HS100-2008unipolar10023.26.42.8811009801.7
parallel2.81.66.44.0
Series1.46.425.64.0
JK60HS111-2008unipolar1112.04.48.33.28120011201.9
parallel2.82.28.34.5
Series1.48.833.24.5
CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS



CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS





CNC Machine NEMA 24 Stepper Motor with CE ISO RoHSCNC Machine NEMA 24 Stepper Motor with CE ISO RoHSCNC Machine NEMA 24 Stepper Motor with CE ISO RoHSCNC Machine NEMA 24 Stepper Motor with CE ISO RoHS

CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS

CNC Machine NEMA 24 Stepper Motor with CE ISO RoHS
CNC Machine NEMA 24 Stepper Motor with CE ISO RoHSCNC Machine NEMA 24 Stepper Motor with CE ISO RoHS









Contact us if you need more details on Stepper Motor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about NEMA 24 Stepper Motor、Electric Motors. If these products fail to match your need, please contact us and we would like to provide relevant information.
