NEMA 24 60*60mm High Performance Electric Stepper Motor

Product Description




               60mm 2phase Hybrid Stepper Motor for cnc machine



General Specification:

Step Angle  Accuracy: ±5%
Resistance Accuracy: ±10%
Inductance Accuracy: ±20%
Temperature Rise: 80°C Max
Ambient Temperature: -20°C~+50°C
Insulation Resistance: 100MΩ Min., 500VDC
Dielectric Strength:  500VAC for one minute
Shaft Radial Play:  0.02Max (450g-load)
Shaft Axial Play: 0.08Max (450g-load)
NEMA 24 60*60mm High Performance Electric Stepper Motor
Specification
Model No.
Motor Length

Current
/Phase

Resistance
/Phase

Inductance
/Phase

Holding Torque

# of Leads

Detent Torque

Rotor Inertia

Mass
 (L)mmAΩmHN.mNo.g.cmg.cmKg
JK60HS56-2008unipolar5621.83.1.1787003000.77
parallel2.80.93.61.65
Series1.43.614.41.65
JK60HS67-2008unipolar6722.44.61.589005701.2
parallel2.81.24.62.1
Series1.44.818.42.1
JK60HS88-2008unipolar88236.82.2810008401.4
parallel2.81.56.83.1
Series1.4627.23.1
JK60HS100-2008unipolar10023.26.42.8811009801.7
parallel2.81.66.44.0
Series1.46.425.64.0
JK60HS111-2008unipolar1112.04.48.33.28120011201.9
parallel2.82.28.34.5
Series1.48.833.24.5
NEMA 24 60*60mm High Performance Electric Stepper Motor



NEMA 24 60*60mm High Performance Electric Stepper Motor





NEMA 24 60*60mm High Performance Electric Stepper MotorNEMA 24 60*60mm High Performance Electric Stepper MotorNEMA 24 60*60mm High Performance Electric Stepper MotorNEMA 24 60*60mm High Performance Electric Stepper Motor

NEMA 24 60*60mm High Performance Electric Stepper Motor

NEMA 24 60*60mm High Performance Electric Stepper Motor
NEMA 24 60*60mm High Performance Electric Stepper MotorNEMA 24 60*60mm High Performance Electric Stepper Motor









Contact us if you need more details on Stepper Motor NEMA 24. We are ready to answer your questions on packaging, logistics, certification or any other aspects about NEMA 24 Stepper Motor、Electric Motors. If these products fail to match your need, please contact us and we would like to provide relevant information.
